Glass-passivated Case: Molded plastic Epoxy: UL 94V-0 rate flame retardant Lead: Axial leads, solderable per MIL-STD-202, method 208 guaranteed Polarity: Color band denotes cathode end Mounting position: Any Weight: 1.1050 grams (approximately)
Rating 25°C ambient temperature unless otherwise specified. Single phase half wave, 60Hz, resistive or inductive load. For capacitive load, derate current by 20%.
Max. Repetitive Peak Reverse Voltage Max. RMS Voltage Max. DC Blocking Voltage Max. Average Forward Rectified Current 0.375" (9.5 mm) Lead Length = 55°C Peak Forward Surge Current 8.3 ms single half sine-wave superimposed on rated load (JEDEC method) Max. Instantaneous Forward Voltage at 5.0A Max. DC Reverse Current at Rated DC Blocking Voltage = 100°C
Maximum Reverse Recovery Time (Note 1) Typical Junction Capacitance (Note 2) Storage temperature
Notes: 1. Reverse Recovery Time test conditions: 1.0 A, IRR A 2. Measured at 1 MHz and applied reverse voltage 4.0 V D.C.
