SS32 SS33 SS34 SS35 SS36 SS38 SS310
CY
Model No.: SS32 SS33 SS34 SS35 SS36 SS38 SS310
Brand: CY
Supply Type: Original Manufacturer
Reference Materials: Datasheet
Place Of Origin: China
Species: Zener Diode, Rectifier Diode
Package Type: Surface Mount
Productivity: 2KK
Transportation: Ocean,Air,Express
Place of Origin: CHANGZHOU,CHINA
Supply Ability: 1KK
Certificate: ISO9000
Port: Shanghai
Payment Type: L/C,T/T
Incoterm: FOB,EXW
Selling Units:
Others
Diode , an electronic device with two electrodes that allows current to flow in a single direction only.Many diodes are used to apply their rectifying function.At the same time, diodes should be designed as electronic adjustable capacitors.
Features
. Case: JEDEC DO-214AC. molded plastic
. Terminals: Axial leads. Solderable per MIL-STD-750 Method 2026
. Polarity: Color band denotes cathode
. Weight: 0.003 ounce. 0.093 grams
. Mounting position: Any
Electrical Characteristics
TYPE | Max Reverse Voltage | Max Forward Current | Max Forward Voltage | Max Reverse Current |
Vrrm | Iav | Vf | Ir | |
V | A | V | mA | |
SS32 | 20 | 3 | 0.55 | 0.1 |
SS33 | 30 | 3 | 0.55 | 0.1 |
SS34 | 40 | 3 | 0.55 | 0.1 |
SS35 | 50 | 3 | 0.7 | 0.1 |
SS36 | 60 | 3 | 0.7 | 0.1 |
SS38 | 80 | 3 | 0.85 | 0.1 |
SS310 | 100 | 3 | 0.85 | 0.1 |
ChangZhou Changyuan Electronics Co.,Ltd is located in ChangZhou High-tech Industry Development Zone. It is an electronic manufacturing company specializing in the R & D, sealing, testing, producing and saling of diodes, The company covers an area of 6600m² and a building area of 16,000 m²
Changyuan Electronics has domestic advanced diode production equipment, perfect testing methods and quality assurance system. Our main products includes plastic silicon diodes, switching diodes, high efficiency Rectifiers, DIAC,schottky rectifiers, Diodes for energy-saving lamps and for switching power supplies etc.
Changyuan Electronics has achieved rapid development with the support of our customers and leaders at levels. Now we have a production capacity of 300KK various diodes per month, mainly including 1A, 1.5A, 2A, 3A, 6ASTD; FR; HER; SF; SKY, DB3, TVS, TO-220 etc. Our products are widely used in household appliances, green lighting, network communications, power chargers, automotive electronics and other fields, the quality and corporate recognition enjoy a high reputation in the industry and customers.We mainly provides supporting services for domestic well-known enterprises and Taiwan-funded enterprises, and our own brand products occupy a certain market share in China, Europe, America, Korea, India and other countries.
Changyuan Electronics focuses on research and development, technology investment and employee training. The company's technical backbone accounts for 30% of the number of employees and is growing year by year.The strong technical team, standardized production process and perfect quality assurance system ensure product quality and after-sales service.
Changyuan Electronics strictly implements ISO9001-2008 quality standards, comprehensively implements scientific management and standardized management, and is committed to creating a first-class electronic discrete device manufacturing enterprise. We have always adhered to the business philosophy of "integrity, pragmatism and standardization", adhering to the quality policy of "high quality, high efficiency, standardization" . We keep the values of "employee dedication, customer satisfaction, and social recognition", with the goal of producing first-class products, cultivating first-class talents, and achieving first-class enterprises, forge ahead, develop steadily, return customers with integrity, and give back to society and sustainable operation Corporate mission.
