KBPC5010
CY
Model No.: KBPC5010
Brand: CY
Supply Type: Original Manufacturer
Reference Materials: Datasheet
Place Of Origin: China
Species: Led
Packaging: Carton
Productivity: 2KK
Transportation: Ocean
Place of Origin: CHINA
Supply Ability: 1KK
Certificate: ISO9001
Port: Shanghai
Payment Type: T/T
Incoterm: FOB,EXW
Selling Units:
Others
Package Type:
Carton
Features
. The plastic package carries Underwriters Laboratory Flammability Classification 94V-0
. Ideal for printed circuit boards
. Low reverse leakage
. High forward surge current capability
. High temperature soldering guaranteed: 260 C/10 seconds,5 lbs. (2.3kg) tension
Mechanical Data
. Case:Metal case
. Terminals: Lead 0.040" (1.02mm) diameter
. Polarity: Polarity symbols marked on case
. Mounting:Thru hole for #8 screw,20in.-lbs. torque max.
. Weight: 0.93 ounce, 26.4 grams
Electrical Characteristics
Symbol | KBPC50005 | KBPC5001 | KBPC5002 | KBPC5004 | KBPC5006 | KBPC5008 | KBPC5010 | Units | |
Max Reverse Voltage | Vrrm | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | V |
Max Forward Current | Iav | 35 | A | ||||||
Max Forward Voltage | Vf | 1.1 | V | ||||||
Max Reverse Current | Ir | 10 | μA |
Tape&Box Packing
Package | Box QTY (pcs) | Tape Size (mm) | Box Size (mm) | Carton Size (mm) | Carton QTY (pcs) | Gross Weight (kg) |
DO-41 | 5000 | 52 | 255*80*140 | 430*280*310 | 50000 | 17 |
DO-15 | 3000 | 52 | 255*80*140 | 430*280*310 | 30000 | 14 |
Do-27 | 1000 | 52 | 255*80*140 | 430*280*310 | 10000 | 12 |
R-6 | 500 | 52 | 255*80*140 | 430*280*350 | 5000 | 11 |
Changzhou Changyuan Electronic Co.,Ltd
Professional and leading diode manufacturer in China with ROHS and ISO9001:2008 certification.
Products: silicon diode, switching diode, high efficiency diode, trigger diode, Schottky Diode,SMD diode, energy saving lamp diode and switching power supply diode.
Production capacity: 300,000,000 pieces of diodes per month.
Top quality: OEM for Good-ark electronic, Star Sea electronic and cooperate with Pentium electrical, NVC, TCL, Honeywell Lonon etc.
